Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP66 |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP66 |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Material |
Copper-free aluminium, powder coated surface, yellow (RAL1021) Toughened glass, stands 4J impact |
|
Weight |
9.2~26.6kg |
|
Dimensions |
278X278X335mm |
|
Lamp specification |
LED module, Multiple LED |
|
Lamp power (W) |
120W, 160W |
|
Rated voltage |
100~277V AC 50/60Hz,130~250V DC |
|
Earthing protection |
M5( Internal & External earth bolts) |
|
Terminal |
3 x 1.5~4mm2 (L+N+PE) |
|
Cable entries |
1~4 |
|
Cable gland |
DQM-II (Ex d) or DQM-III (Ex d) is recommended. |
