Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP66 |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP66 |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Material |
Polycarbonate, stands 7J impact, corrosion-proof Diffuser Polycarbonate, high light transmission, stands 7J impact, corrosion-proof |
|
Weight |
2.25~5.25kg |
|
Dimensions |
1360x170x114mm |
|
Lamp specification |
T8 tube |
|
Lamp power (W) |
36W（18W） x 2； 36W（18W） x 1 |
|
Emergency power (W) |
36W x 1 |
|
Emergency starting time |
0.3s |
|
Charging time |
24h |
|
Emergency lighting time |
120/180 Mins |
|
Rated voltage |
100~300V AC 50/60Hz |
|
Rated luminous flux |
1300~6500lm |
|
Terminal |
3 x 1.5~4mm2 (L+N+PE) |
|
Cable entries |
4 |
|
Available cable outer diameter |
Φ9~Φ16 (mm) |
