Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP66 |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP66 |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Material |
Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) |
|
Weight |
5.32~10.9kg |
|
Dimensions |
φ1665x180x165mm |
|
Lamp specification |
T8;T5;LED module |
|
Lamp power (W) |
T8: 18W(36W/58W)x2 T5: 14W(28W/35W)x2 LED:9W(18W/28W)x2 |
|
LED Color temperature |
5000K |
|
Earth protection |
M5 (internal & external earth bolts) |
|
Rated voltage |
T8/T5: 100-305V AC 50/60Hz; LED: 100-275V AC 50/60Hz |
|
Rated luminous flux |
1999~10000lm |
|
Terminal |
3 x 1.5~4mm2 (L+N+PE) |
|
Cable entries |
2 |
|
Cable gland(optional) |
DQM-II (Ex d) or DQM-III (Ex d) is recommended. |
