Global (IECEx) |
IECEx CQM 12.0046X |
|
|
Gas and dust |
Ex nA IIC T4 Gc Ex t IIIC T80℃ Db IP66 |
|
|
Europe (ATEX) |
LCIE 12 ATEX 1009X (gas) LCIE 12 ATEX 3019X (dust) |
|
|
Gas and dust |
II 3 G Ex nA IIC T4 Gc |
|
|
|
II 2 D Ex t IIIC T80℃ Db IP66 |
|
|
Certificates |
IECEx; ATEX; CU-TR |
|
|
Conformity to standards |
EN; IEC |
|
|
Degree of protection |
IP65 |
|
|
Available lamp |
Halogen tungsten lamp (LED on request) |
|
|
Lamp power (W) |
2 x 10W (LED lamp power: 2 x 1W) |
|
|
Emergency time |
90min |
|
|
Rated luminous flux |
Halogen tungsten lamp: 2 x 100lm (LED lamp: 2 x 90lm) |
|
|
Description |
Ni-MH battery |
|
|
Rated capacity |
6Ah |
|
|
Rated voltage |
6V |
|
|
Charging current |
300mA |
|
|
Discharging current |
1000mA |
|
|
Charging time |
24h |
|
|
Ambient temperature |
-20℃~+55℃ |
|
|
Terminal |
3 x 1.5~2.5mm2 (L+N+PE) |
|
|
Cable entries |
2 x M25 x 1.5 plugs |
|
|
Cable gland (optional) |
DQM-II (Ex d) or DQM-III (Ex d) is recommended. |
|
|
Weight |
5.05kg |
