Global (IECEx) |
IECEx LCI 08. 0008 |
|
Gas and dust |
Ex d IIC T6 Gb |
|
|
Ex tb IIIC T80℃ Db |
|
Europe (ATEX) |
LCIE 06 ATEX 6068 |
|
Gas and dust |
II 2 G Ex d IIC T6 Gb |
|
|
II 2 D Ex tb IIIC T80℃ Db |
|
Certificates |
IECEx; ATEX; CU-TR |
|
Conformity to standards |
EN; IEC |
|
Degree of protection |
IP66 |
|
Ambient temperature |
-60℃~+60℃ |
|
Enclosure |
Copper-free Aluminium Alloy, powder coated surface, yellow (RAL1021) |
|
Exposed fastener |
Stainless steel |
|
Rated voltage |
100~300V AC 50/60Hz |
|
Lamp |
LED lamp (working voltage DC 3.6V) |
|
Power consumption |
4W |
|
Emergency time |
180min |
|
Rated capacity |
800mAh |
|
Charging time |
16h |
|
Earthing protection |
M5 (internal & external earth bolts) |
|
Ambient temperature |
-40℃~+60℃, -60℃~+60℃ |
|
Terminal |
3 x 1.5~2.5mm² (L+N+PE) |
|
Cable entries |
2 x M25 x 1.5 plugs |
|
Cable gland |
DQM-II (Ex d) or DQM-III (Ex d) is recommended. |
|
Weight |
5.15kg |
