Global (IECEx) |
IECEx CNEX 19.0015X |
|
Gas and dust |
Ex db IIC T6 Gb Ex tb IIIC T80℃ Db IP66 |
|
Europe (ATEX) |
CNEX 19 ATEX 0023X |
|
Gas and dust |
II 2 G Ex db IIC T6 Gb II 2 D Ex tb IIIC T80℃ Db IP66 |
|
Certificates |
IECEx; ATEX; CU-TR |
|
Conformity to standards |
EN;IEC |
|
Degree of protection |
IP66 |
|
Ambient temperature |
-60℃~+60℃
|
|
Material |
Copper-free Aluminium Alloy, powder coated surface |
|
Weight |
2.6kg~20kg |
|
Dimensions |
As per design |
|
Enclosure colour |
Window grey (RAL7040) |
|
Exposed fastener |
Stainless steel |
|
Rated voltage |
Max. 690V AC |
|
Rated current |
16A~125A |
|
Internal&external earthing |
M5/M5 |
|
Cross section of cable |
2.5~4mm2 |
|
Cable gland(optional) |
DQM-II(Ex d), DQM-III(Ex d) |
