Contactor, TeSys K, 3P, AC-3/AC-3e,440V 6A, 1NO aux, 24V AC coil.
| Specifications | ||
| Range | TeSys | |
| Country of Origin (Estimated) | Indonesia (Other) | |
| Warranty | 12 months | |
| CO/CQ | Yes (if) | |
| Product name & Device short name | LC1K | |
| Device application | Control | |
| Poles description | 3P | |
| [Ie] rated operational current | 6 A (at <60 °C) at <= 440 V AC AC-3 for power circuit 6 A (at <60 °C) at <= 440 V AC AC-3e for power circuit |
|
| [Ue] rated operational voltage | Power circuit: <= 690 V AC <= 400 Hz Signalling circuit: <= 690 V AC <= 400 Hz |
|
| [Uc] control circuit voltage | 24 V AC 50/60 Hz | |
| Standards | EN/IEC 60947-4-1 GB/T 14048.4 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 |
|
| Pole contact composition | 3 NO | |
| Auxiliary contact composition | 1 NO | |
| Maximum operating rate | 3600 cyc/h | |
| Dimensions (mm) (HxWxD) |
58x45x57 mm | |
| Net weight (Kg) | 0.18 Kg | |
| Motor power kW | 2.2 kW at 380...415 V AC 50/60 Hz AC-3 3 kW at 440/690 V AC 50/60 Hz AC-3 |
|
