Drives ACS580 3P 380-480VAC 7.5KW, IN: 17A, Size R2, Assistant control panel.
Specifications: ACS580-01-018A-4+J400 |
||
| Range | Drives ACS580 | |
| Country of Origin (Estimated) | China (CN) (Other) | |
| Warranty | 12 months | |
| CO/CQ | Yes (if need) | |
| Global Commercial Alias | ACS580-01-018A-4+J400 | |
| Control panel and panel | Assistant control panel (+J400-ACS-AP-S) | |
| Product ID | 3AXD50000038959 | |
| Variable speed drive application selection | Pumps, Fans, Compressors, Conveyors, Mixers | |
| Product destination | Synchronous reluctance motors | |
| Mounting Type: | Wall-mounted | |
| Network number of phases | 3 phase | |
| Supply voltage limits | 380 ... 480 V | |
| IP degree of protection | IP21 | |
| EMC according to EN 61800-3: 2004 + A1: 2012 | ACS580 with built-in C2 category filter as standard | |
| Output Power, Normal Use (Pn) | 7.5 kW | |
| Output Current, Normal Use (In): | 17 A | |
| Communication port protocol | CAN DeviceNet EtherNet/IP MODBUS Other Bus Systems PROFIBUS PROFINET IO TCP/IP |
|
| Motor control | Scalar and vector control | |
| Functional safety | Safe Torque Off | |
| Frequency (f): | 0 to 500 Hz | |
| Frame Size: | R2 | |
| Dimensions (mm) (H x W x D) |
473x125x229 mm | |
| Net weight (Kg) | 6.6 Kg | |
