Global (IECEx) |
IECEx CQM 15.0061X |
Gas and dust |
Ex db IIC T6 Gb |
|
|
Ex tb IIIC T80℃ Db IP66 |
Europe (ATEX) |
CNEX 16 ATEX 0006 |
Gas and dust |
II 2 G Ex db IIC T6 Gb |
|
|
II 2 D Ex tb IIIC T80℃ Db IP66 |
Certificates |
IECEx; ATEX; CU-TR;UL |
Conformity to standards |
EN;IEC |
Degree of protection |
IP66 |
Ambient temperature |
-60℃~+60℃ |
Material |
Copper-free Aluminium Alloy, powder coated surface |
Weight |
1.2kg |
Dimensions |
146mm×163mm×100mm |
Enclosure colour |
Window grey (RAL7040) |
Exposed fastener |
Stainless steel |
Rated voltage |
Max. 500V AC |
Rated current |
24A, 32A, 41A |
Internal&external earthing |
M5/M5 |
Cable gland(optional) |
DQM-II(Ex d), DQM-III(Ex d) |
