Material |
Copper-free Aluminium Alloy or cast iron, powder coated surface |
|
Weight |
0.7kg~2.1kg |
|
Dimensions |
117mm×122×80mm |
|
Enclosure colour |
Yellow (RAL1021) |
|
Exposed fastener |
Stainless steel |
|
Rated voltage |
Max. 500V AC |
|
Rated current |
20A |
|
Internal&external earthing |
M4/M5 |
|
Cable gland(optional) |
DQM-II(Ex d), DQM-III(Ex d) |
|
Global (IECEx) |
IECEx CQM 11.0022X |
|
Gas and dust |
Ex db IIC T6 Gb |
|
|
Ex tb IIIC T80℃ Db IP66 |
|
Europe (ATEX) |
LCIE 11 ATEX 3005 |
|
Gas and dust |
II 2 G Ex db IIC T6 Gb |
|
|
II 2 D Ex tb IIIC T80℃ Db IP66 |
|
Certificates |
IECEx; ATEX; CU-TR |
|
Conformity to standards |
EN; IEC |
|
Degree of protection |
IP66 |
|
Ambient temperature |
-60℃~+60℃ |
